General Profibus DP interface data
●
Baud rate and maximum cable length (segment length) without repeater:
-
between 9.6 and 93.75 kbit/s: 1,200 m
-
for 187.5 kbit/s: 1,000 m
-
for 500 kbit/s: 400 m
-
for 1,500 kbit/s: 200 m
●
Baud rate and possible cable length with repeater (total network cable length):
-
between 9.6 and 93.75 kbit/s: approx. 10 km
-
for 187.5 kbit/s: approx. 10 km
-
for 500 kbit/s: approx. 4 km
-
for 1,500 kbit/s: approx. 2 km
Transmission speed/cable
length
●
DP master class 1, e.g. central controllers such as PLC, PC, ...
●
DP master class 2, e.g. programming/configuration tools
●
DP slave, e.g. devices with digital and/or analogue inputs/outputs such as actuators,
sensors
Device types
32 devices without repeater, with repeater expandable to 126Number of devices
●
Token-passing between masters and polling for slaves
●
Mono-master or multi-master systems are possible.
Bus access
Cyclic data exchange, sync mode, freeze mode, fail-safe modeSupported fieldbus functions
0x0C4F: Standard applications with Profibus DP-V0 and DP-V1
0x0CBD: Applications with Profibus DP-V2
Profibus DP ident no.
