AUMA AUMATIC AC 01.2 User Manual

ExplanationSetting valueDefaultAccessParametersTypeNo.
Raw value end position
CLOSED
0R
Raw val. pos. CLOSED
U1669-4
65535
Potentiometer raw value /mV
0R
Potent. raw value /mV
U1669-5
5000 [mV]
Table 83: Profibus DP1
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 15 bytes
Profibus DP channel 1; current
slave address
Min = 0R
DP1 slave address
U856-1
Max = 126
Profibus DP channel 1; baud
rate
0 : 12 Mbit/s
R
DP1 baud rate
enum56-2
1 : 6 Mbit/s
2 : 3 Mbit/s
3 : 1.5 Mbit/s
4 : 500 kbit/s
5 : 187.5 kbit/s
6 : 93.75 kbit/s
7 : 45.45 kbit/s
8 : 19.20 kbit/s
9 : 9.6 kbit/s
15 : Not available
Profibus DP channel 1; watch-
dog status
0 : Baud search
R
DP1 watchdog status
enum55-3
1 : Baud control
2 : DP control
Profibus DP channel 1; Profibus
status
0 : Wait Prm
R
DP1 Profibus status
enum55-4
1 : Wait Cfg
2 : Data Ex
Profibus DP channel 1; Global
Control Clear
0 : GC Clear inactive
R
DP1 GC clear
enum55-5
1 : GC Clear active
Profibus DP channel 1; data
length 0
0 : Data length 0 inactive
R
DP1 data length 0
enum55-6
1 : Data length 0 active
Profibus DP channel 1; Global
Control Freeze
0 : GC Freeze inactive
R
DP1 GC freeze
enum55-7
1 : GC Freeze active
Profibus DP channel 1; Global
Control Sync
0 : GC Sync inactive
R
DP1 GC sync
enum55-8
1 : GC Sync active
Table 84: Profibus DP2
ErläuterungSetting valueDefaultAccessParametersTypeNo.
Data length = 15 bytes
Profibus DP channel 2; current
slave address
Min = 0R
DP2 slave address
U856-1
Max = 126
Profibus DP channel 2: baud
rate
0 : 12 Mbit/s
R
DP2 baud rate
enum56-2
1 : 6 Mbit/s
2 : 3 Mbit/s
3 : 1.5 Mbit/s
4 : 500 kbit/s
5 : 187.5 kbit/s
6 : 93.75 kbit/s
7 : 45.45 kbit/s
8 : 19.20 kbit/s
9 : 9.6 kbit/s
15 : Not available
80
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
