AUMA AUMATIC AC 01.2 User Manual

ErläuterungSetting valueDefaultAccessParametersTypeNo.
Profibus DP channel 2; watch-
dog status
0 : Baud search
R
DP2 watchdog status
enum56-3
1 : Baud control
2 : DP control
Profibus DP channel 2: Profibus
status
0 : Wait Prm
R
DP2 Profibus status
enum56-4
1 : Wait Cfg
2 : Data Ex
Profibus DP channel 2: Global
Control Clear
0 : GC Clear inactive
R
DP2 GC clear
enum56-5
1 : GC Clear active
Profibus DP channel 2; data
length 0
0 : Data length 0 inactive
R
DP2 data length 0
enum56-6
1 : Data length 0 active
Profibus DP channel 2: Global
Control Freeze
0 : GC Freeze inactive
R
DP2 GC freeze
enum56-7
1 : GC Freeze active
Profibus DP channel 2; Global
Control Sync
0 : GC Sync inactive
R
DP2 GC sync
enum56-8
1 : GC Sync active
Table 85: Profibus details
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 16 bytes
DP-V1 control active
Min = 0R
DP-V1 control
BOOL57-1
Max = 1
DP-V1 connection active
Min = 0R
DP-V1 active
BOOL57-2
Max = 1
Channel 1 is the active opera-
tion command channel
Min = 0R
Channel 1 active
BOOL57-3
Max = 1
Channel 2 is active operation
command channel
Min = 0R
Channel 2 active
BOOL57-4
Max = 1
Primary0 : None
R
Primary
enum57-5
1 : Channel 1
2 : Channel 2
Backup0 : None
R
Backup
enum57-6
1 : Channel 1
2 : Channel 2
Profibus ID no.3151 : 0x0C4F
3151R
Profibus ID no.
enum57-7
3261 : 0x0CBD
3191 : 0x0C77
Redundancy0 : None
0R/W
Redundancy
enum57-8
1 : DP-V2 (SR)
4 : DP-V2 (FR)
2 : AUMA redundancy I
3 : AUMA redundancy II
DP-V1 function in the parameter
telegram (SetPrm)
0 : Deactivated
R
DP-V1 (SetPrm)
enum57-9
1 : Activated
Signalling alarms in the paramet-
er telegram (SetPrm)
0 : Deactivated
R
Alarms (SetPrm)
enum57-10
1 : Activated
81
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Appendix
