Table 90: Characteristics
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 62 bytes
Tag for torque-position charac-
teristic 1
_ REF 1 _R/W
Tag torque-position 1
S2065-1
Tag for torque-position charac-
teristic 2
_ REF 2 _R/W
Tag torque-position 2
S2065-2
Tag for torque-position charac-
teristic 3
_ REF 3 _R/W
Tag torque-position 3
S2065-3
Interval position-time
Min = 1 [s]10R/W
Interval position-time
U1665-4
Max = 3600 [s]
Table 91: Device temperatures
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 8 bytes
Temperature of the controls
Min = -60 [C°]R
Temp. controls
I1662-1
Max = 150 [C°]
Temperature of the control unit
Min = -60 [C°]R
Temp. control unit
I1662-2
Max = 150 [C°]
Temp. motor
Min = -60 [C°]R
Temp. motor
I1662-3
Max = 150 [C°]
Temperature of the gearbox
Min = -60 [C°]R
Temp. gearbox
I1662-4
Max = 150 [C°]
Table 92: Controls version
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Version for explosion-proof ap-
plications
0 : Off
0R
Ex version
enum63-1
1 : On
Version for applications with hy-
draulic actuators
0 : Off
0R
Hydraulic version
enum63-2
1 : On
0: Off
0R
SIL version
enum63-3
1: On
Table 93: Hardware equipment
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 44 bytes
Target configuration of 'LC'
(Local Controls/ A9) electronics
sub-assembly
0 : Not available
1R
LC (target)
enum64-1
1 : Available
'LC' (Local Controls) electronics
sub-assembly (A9)
0 : Not available
0R
LC
enum64-2
1 : Available
'Logic' (target configuration)
electronics sub-assembly (A2)
0 : Not available
1R
Logic (target)
enum64-3
1 : Available
'Logic' electronics sub-assembly
(A2)
0 : Not available
0R
Logic
enum64-4
1 : Available
Target configuration of position
transmitter
0 : None
1R
Pos. transm. (target)
enum64-5
1 : Potentiometer
2 : RWG
4 : MWG
Type of position transmitter
used
0 : None
0R
Position transmitter
enum64-6
1 : Potentiometer
2 : RWG
4 : MWG
