Byte 7: Digital outputs 1
The digital outputs Fieldbus DOUT 1 – DOUT 6 of the fieldbus interface can be used
as commands for the output contact. For this, the outputs of the output contacts have
to be assigned with the signals Fieldbus DOUT 1 – Fieldbus DOUT 6.
Table 31: Byte 7: Digital outputs 1
DescriptionValueDesignation
(process representation)
Bit
No command (reserved)—0
No command (reserved)—1
No command (reserved)—2
No command (reserved)—3
No command (reserved)—4
No command (reserved)—5
No command (reserved)—6
No command (reserved)—7
Byte 8: Digital outputs 2
Table 32: Byte 8: Digital outputs 2
DescriptionValueDesignation
(process representation)
Bit
Digital output 1 is activated.1
Fieldbus DOUT 1
0
Output is deactivated.0
Digital output 2 is activated.1
Fieldbus DOUT 2
1
Output is deactivated.0
Digital output 3 is activated.1
Fieldbus DOUT 3
2
Output is deactivated.0
Digital output 4 is activated.1
Fieldbus DOUT 4
3
Output is deactivated.0
Digital output 5 is activated.1
Fieldbus DOUT 5
4
Output is deactivated.0
Digital output 6 is activated.1
Fieldbus DOUT 6
5
Output is deactivated.0
No command (reserved)—6
No command (reserved)—7
Bytes 9 and 10: Actual process value
Byte 9 = high byte, byte 10 = low byte.
Byte 9 and byte 10 in combination with a process controller (option) can be used to
transmit the actual process value.
Bytes 11 and 12: Fieldbus output AOUT 1
Byte 11 = high byte, byte 12 = low byte.
Bytes 11 and 12 can be used to send an analogue value to the actuator.
The value is transmitted in per mil (value: 0 – 1,000). 0 – 1000
The outputs "Fieldbus output AOUT 1" and "Fieldbus output AOUT 2) can be used
as output values via the analogue outputs. For this, the outputs of the analogue
outputs have to be assigned with the signals Fieldbus AOUT 1 or Fieldbus AOUT 2.
Bytes 13 and 14: Fieldbus output AOUT 2
Byte 13 = high byte, byte 14 = low byte.
A second analogue value can be sent to the actuator using bytes 13 and 14.
39
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Description of the data interface
