Table 39: Alarms
RemarkBitByte
01234567
Type of signal
0x01 = Delta_Trigger_Discrete
0x02 = Time_Trigger_Discrete
0x80 = Start-up data
0x84 = End of time stamp
0x85 = Buffer overrun
0x86 = Channel change-over for re-
dundancy
0x87 = Loss of information for redund-
ancy
000100001
Slot000000002
Signal
1 = End position CLOSED
2 = End position OPEN
3 = Torque sw. CLOSED
4 = Torque sw. OPEN
5 = Selector sw. REMOTE
6 = Fault
7 = Phase fault
3
Status of the indication
Active = 1: Indication active (rising
signal flank)
Active = 0: Indication not active (fall-
ing signal flank)
Active4
Not used5
Not used6
Time- stampSeconds (2
31
.. 0) since 1.1.1900 0:00,00
or
if value< 0x9DFF4400 since 7.2.2036 6:28,16
7
8
9
10
Split seconds (2
31
.. 0) unit: 1/2
32
seconds11
12
13
14
Time stamp and redundancy
Time-stamped data is only sent via the primary channel. During a channel
change-over, the time-stamped indications are buffered and sent to the master after
change-over. In case of a buffer overrun, the startup data is sent.
50
Actuator controls
Description of the data interface AC 01.2/ACExC 01.2 Profibus DP
