General Profibus DP interface data

●

Baud rate and maximum cable length (segment length) without repeater:

between 9.6 and 93.75 kbit/s: 1,200 m

for 187.5 kbit/s: 1,000 m

for 500 kbit/s: 400 m

for 1,500 kbit/s: 200 m

●

Baud rate and possible cable length with repeater (total network cable length):

between 9.6 and 93.75 kbit/s: approx. 10 km

for 187.5 kbit/s: approx. 10 km

for 500 kbit/s: approx. 4 km

for 1,500 kbit/s: approx. 2 km

Transmission speed/cable

length

●

DP master class 1, e.g. central controllers such as PLC, PC, ...

●

DP master class 2, e.g. programming/configuration tools

●

DP slave, e.g. devices with digital and/or analogue inputs/outputs such as actuators,

sensors

Device types

32 devices without repeater, with repeater expandable to 126Number of devices

●

Token-passing between masters and polling for slaves

●

Mono-master or multi-master systems are possible.

Bus access

Cyclic data exchange, sync mode, freeze mode, fail-safe modeSupported fieldbus functions

0x0C4F: Standard applications with Profibus DP-V0 and DP-V1

0x0CBD: Applications with Profibus DP-V2

Profibus DP ident no.

Actuator controls

AC 01.2/ACExC 01.2 Profibus DP Technical data
