AUMA AUMATIC ACExC 01.2 User Manual

Table 54: Profibus DP
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Profibus DP slave address
Min = 0126R/W
DP1 slave address
U1613-1
Max = 126
Profibus DP slave address,
channel 2
Min = 0126R/W
DP2 slave address
U1613-2
Max = 126
Table 55: Positioner
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 30 bytes
Setting the adaptive behaviour
of the positioner
0 : Off
0R/W
Adaptive behaviour
enum14-1
1 : Adaptive I
Setting the dead time
Min = 2 [0.1 s]5R/W
Dead time
U1614-2
Max = 600 [0.1 s]
Setting dead band OPEN (irrel-
evant for adaptive behaviour)
Min = 0 [0.1 %]5R/W
Dead band OPEN
U1614-3
Max = 100 [0.1 %]
Setting dead band CLOSE (irrel-
evant for adaptive behaviour)
Min = 0 [0.1 %]5R/W
Dead band CLOSE
U1614-4
Max = 100 [0.1 %]
Hysteresis in direction OPEN
(for adaptive positioner only)
Min = 0 [0.1 %]5R/W
Positioner hyst. OPEN
U1614-5
Max = 50 [0.1 %]
Hysteresis in direction CLOSE
(for adaptive positioner only)
Min = 0 [0.1 %]5R/W
Positioner hyst.
CLOSE
U1614-6
Max = 50 [0.1 %]
Tolerance for the function
"Closing fully" for end position
CLOSED
Min = 0 [0.1 %]0R/W
Tolerance CLOSE
I3214-7
Max = 50 [0.1 %]
Tolerance for the function
"Opening fully" for end position
OPEN
Min = 950 [0.1 %]1000R/W
Tolerance OPEN
I3214-8
Max = 1000 [0.1 %]
Permissible number of starts/h
(only in combination with Adapt-
ive behaviour = Adaptive II)
Min = 11200R/W
Permissible starts/h
U1614-9
Min = 1800
Setting the outer dead band (ir-
relevant for adaptive behaviour)
Min = 1 [0.1 %]10R/W
Outer dead band
U1614-10
Max = 100 [0.1 %]
Function Limit positioner range0 : Function not active
0R/W
Limit positioner range
enum14-11
1 : Function active
Limit OPEN
Min = 0 [0.1 %]1000R/W
Limit OPEN
U1614-12
Max = 1000 [0.1 %]
Limit CLOSE
Min = 0 [0.1 %]0R/W
Limit CLOSE
U1614-13
Max = 1000 [0.1 %]
Table 56: Process controller
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 26 bytes
Setpoint source of process con-
troller
0 : I/O interface
0R/W
Setpoint source
enum67-1
1 : Fieldbus interface
2 : Internal setpoint
Behaviour on setpoint failure0 : Internal setpoint 1
0R/W
Beh. setpoint failure
enum67-2
1 : Internal setpoint 2
2 : Failure behaviour
Inverse operation0 : Function not active
0R/W
Inverse operation
enum67-3
1 : Function active
Internal setpoint 1 for process
controller
Min = 0 [0.1 %]500R/W
Internal setpoint 1
U1667-4
Max = 1000 [0.1 %]
66
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
