ExplanationSetting valueDefaultAccessParametersTypeNo.
258 : End position OPEN
370 : End p. CLOSED,
blink
369 : End p. OPEN, blink
401 : Setpoint pos.
reached
265 : Running CLOSE
264 : Running OPEN
113 :Selector sw. LOCAL
115 : Selector sw. RE-
MOTE
116 : Selector sw. OFF
376 : Limit switch
CLOSED
375 : Limit switch OPEN
460 : Torque sw.
CLOSED
459 : Torque sw. OPEN
86 : Failure
84 : Function check
83 : Out of specification
85 : Maintenance re-
quired
79 : Fault
78 : Warning
80 : Not ready REMOTE
554 : Op. pause active
560 :Start stepping mode
603 : Actuator running
539 : Running LOCAL
540 : Running REMOTE
541 : Handwheel opera-
tion
549 :In intermed. position
392 : Intermed. pos. 1
399 : Intermed. pos. 2
398 : Intermed. pos. 3
397 : Intermed. pos. 4
396 : Intermed. pos. 5
395 : Intermed. pos. 6
394 : Intermed. pos. 7
393 : Intermed. pos. 8
500 : Input DIN 1
501 : Input DIN 2
505 : Input DIN 3
504 : Input DIN 4
503 : Input DIN 5
502 : Input DIN 6
285 : EMCY stop active
269 :Torque fault CLOSE
Torque fault OPEN
Torque fault
Thermal fault
73
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Appendix
