ExplanationSetting valueDefaultAccessParametersTypeNo.
Inner dead b. OPEN
Min = 0 [0,1 %]R
Inner dead b. OPEN
U3252-7
Max = 1000 [0,1 %]
Inner dead b. CLOSE
Min = 0 [0,1 %]R
Inner dead b. CLOSE
U3252-8
Max = 1000 [0,1 %]
Table 79: On time monitoring
ErläuterungSetting valueDefaultAccessParametersTypeNo.
Data length = 8 bytes
Current on time/h
Min = 0R
On time/h
U3253-1
Max = 3600
Current starts/h
Min = 0R
Starts/h
U3253-2
Max = 3600
Table 80: Process controller
ErläuterungEinstellwertDefaultZugriffParameterTypNr.
Data lenght= 8 Bytes
Process setpoint of PID control-
ler
0 [0,0 %]R
Process setpoint
U1673-1
1000 [0,0 %]
Actual process value of PID
controller
0 [0,0 %]R
Actual process value
U1673-2
1000 [0,0 %]
Op. com. PID contr.
0R
Op. com. PID contr.
U3273-3
0
Table 81: Bluetooth
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 62 bytes
Information for actuator identific-
ation within the plant (e.g. KKS
designation - Power Plant Clas-
sification system)
_GERAETE-
TAG_
R/W
Device tag
S2054-1
Bluetooth address (BD_ADDR)
of controls
XX:XX:XX:XX:XX:XXR
Bluetooth address
S2054-2
Bluetooth address (BD_ADDR)
of the Bluetooth partner
XX:XX:XX:XX:XX:XXR
Bluetooth add.partner
S2054-3
Activate/deactivate Buetooth in-
terface
0 : Function not active
1R/W
Bluetooth
enum54-4
1 : Function active
Table 82: Position transmitter
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 10 bytes
Low limit setting of potentiomet-
er signal range (monitoring the
potentiometer span)
Min = 0610R/W
Low limit Uspan
U1669-1
Max = 1023
Current voltage level difference
of the potentiometer.
Min = 0R
Volt.level diff. potent.
U1669-2
Max = 1023
Raw value end position OPEN
0R
Raw val. pos. OPEN
U1669-3
65535
