AUMA AUMATIC ACExC 01.2 User Manual

ExplanationSetting valueDefaultAccessParametersTypeNo.
Activation of the redundancy
function in the parameter tele-
gram (SetPrm)
0 : Deactivated
R
Redundancy (SetPrm)
enum57-11
1 : Activated
Behaviour Tx0 : Tx active channel
0R
Behaviour Tx
enum57-12
1 : Tx both channels
Table 86: FO
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 28 bytes
FO cable receive level channel
1
0 : Chanel deactivated
R
FOC level channel 1
enum58-1
1 : Level bad!
2 : Level critical, no Rx
3 : Level critical, Rx
4 : Level good, no Rx
5 : Level good, Rx
FO cable receive level channel
2
0 : Chanel deactivated
R
FOC level channel 2
enum58-2
1 : Level bad!
2 : Level critical, no Rx
3 : Level critical, Rx
4 : Level good, no Rx
5 : Level good, Rx
RS-485 format error of FOC
sub-assembly
Min = 0R
FOC RS-485 error
U1658-3
Max = 1
FO cable baud rate0: Invalid
R
FO cable baud rate
enum58-4
1: 9.6 kbit/s
2: 19.2 kbit/s
3: 38.4 kbit/s
4: 45.45 kbit/s
5: 57.6 kbit/s
6: 93.75 kbit/s
7: 115.2 kbit/s
8: 187.5 kbit/s
9: 500.0 kbit/s
10: 1500 kbit/s
11: 3000 kbit/s
12: 6000 kbit/s
13: 12000 kbit/s
FO cables FPGA version
0R
FOC FPGA version
S2058-5
Table 87: Operational info total
ExplanationSetting valueDefaultAccessParameterTypeNo.
Data length = 80 bytes
Motor running time throughout
the lifetime
Min = 0 [s]R
Motor running time
U3259-1
Max = 4294967295 [s]
Number of motor starts
throughout the lifetime
Min = 0 [s]R
Motor starts
U3259-2
Max = 4294967295 [s]
Number of thermal faults
throughout the lifetime
Min = 0 [s]R
Thermal fault
U3259-3
Max = 4294967295 [s]
Number torque faults CLOSE
throughout the lifetime
Min = 0 [s]R
Torque fault CLOSE
U3259-4
Max = 4294967295 [s]
Number of torque faults OPEN
throughout the lifetime
Min = 0 [s]R
Torque fault OPEN
U3259-5
Max = 4294967295 [s]
82
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
