AUMA EQ 40 - Page 18

Figure 18: End stop, sizes EQ 40 – EQ 150
Table 6:
Distance T between screw head and housing wall EQ 40– EQ 150
For 150°/180°
1)
For 90°/120°
1)
Dimensions T [mm]
Special
2)
StandardSpecial
2)
Standard
3129.12725.1T
max.
(+15°)
27.52323.519T (for 90°/120° or 150°/180°)
2416.92012.9T
min.
(–15°)
Refer to name plate for swing angle1)
Special coupling (coupling type ST-01); refer to the order-related technical data sheet for the
coupling type.
2)
Figure 19: End stop, sizes EQ 300 – EQ 600
Table 7:
Distance T between screw head and housing wall EQ 300– EQ 600
For 150°/180°
1)
For 90°/120°
1)
Dimension T [mm]
N/A46T
max.
(+15°)
N/A31T (for 90°/120° or 150°/180°)
N/A16T
min.
(–15°)
Refer to name plate for swing angle1)
18
EQ 40 – EQ 150
Commissioning EQ 300 – EQ 600
