Worm gearboxes
GS 40.3 – GS 125.3
GS 160 – GS 500
Torques up to 360 000 Nm
Lever gearboxes
GF 50.3 – GF 125.3
GF 160 – GF 250
Torques up to 32 000 Nm
Part-turn actuators
AS 6 – AS 50
Torques from 25 to 500 Nm
Operating times for 90° from 4 to 90 s
Part-turn actuators
SG 05.1 – SG 12.1
Torques from 100 to 1 200 Nm
Operating times for 90° from 4 to 180 s
Bevel gearboxes
GK 10.2 – GK 40.2
Torques up to 16 000 Nm
Linear thrust units LE
with multi-turn actuators SA
Thrusts from 4 kN to 217 kN
Strokes up to 500 mm
Running speeds
from 20 to 360 mm/min
Multi-turn actuators
SA 07.1 - SA 16.1 / SA 25.1 - SA 48.1
Torques from 10 to 32 000 Nm
Speeds from 4 to 180 min
-1
Spur gearboxes
GST 10.1 - GST 40.1
Torques up to 16 000 Nm
WERNER RIESTER GmbH & Co. KG
Armaturen- und Maschinenantriebe
Postfach 1362 D - 79373 Müllheim
Tel 07631/809-0 Fax 07631/13218
e-mail riester@auma.com
http://www.auma.com
WERNER RIESTER GmbH & Co. KG
Armaturen- und Maschinenantriebe
Postfach 1151 D - 73747 Ostfildern
Tel 0711/34803-0 Fax 0711/34803-34
e-mail riester@wof.auma.com
DO 01.05.022GB /2.01
Controls AUMA MATIC
with multi-turn actuators SA/ SAR
Torques from 10 to 1 000 Nm
Speeds from 4 to 180 min
-1
