AUMA SAREx 07.2 - Page 14

Table 5:
Weights of multi-turn actuators SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2
with 3-phase AC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
22VDX...SAEx 07.2/
SAREx 07.2
23ADX...
22VDX...SAEx 07.6/
SAREx 07.6
24ADX...
26VDX...SAEx 10.2/
SAREx 10.2
28ADX...
48VDX...SAEx 14.2/
SAREx 14.2
52ADX...
50VDX...SAEx 14.6/
SAREx 14.6
56ADX...
72VDX...SAEx 16.2/
SAREx 16.2
88ADX...
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with 3-phase AC motor, electrical con-
nection in standard version, output drive type B1 and handwheel. For other output drive types, heed
additional weights.
2)
Table 6:
Weights of multi-turn actuators SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2
With 1-phase AC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
28VEX...SAEx 07.2/
SAREx 07.2
31AEX...
28VEX...SAEx 07.6/
SAREx 07.6
31AEX...
40ACX...
32VEX...48-4...SAEx 10.2/
SAREx 10.2
35VEX...48-2...
44ACX... 56-4...
47ACX... 56-2...
63VEX...SAEx 14.2/
SAREx 14.2
65VCX...
67ACX...
67VEX...SAEx 14.6/
SAREx 14.6
70VCX...
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with 1-phase AC motor, electrical con-
nection in standard version, output drive type B1 and handwheel. For other output drive types, heed
additional weights.
2)
14
SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2 Control unit: electronic (MWG)
Transport and storage ACExC 01.2 Non-Intrusive Profinet
