Symbol for CLOSED (valve closed)
Symbol for OPEN (valve open)
Via the menu to parameter
Describes the menu path to the parameter. When using the push buttons of local
controls, the required parameter can be quickly found on the display. Display texts
are shaded in grey: Display.
Wiring diagram
Texts extracted from other documents
Texts extracted from other documents are highlighted in a different font. For example
Wiring diagram.
➥
Result of a process step
Describes the result of a preceding process step.
7
SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2 Control unit: electronic (MWG)
ACExC 01.2 Non-Intrusive Profinet Safety instructions
