Features and functions
Without integration into a superordinate automation system (stand-alone mode)
SIMA² is operated in stand-alone mode; the operation commands for the AUMA actuators
are entered manually by the operator via the user interface.
Standard:Communication between SIMA² and
host
Modbus RTU in single-channel or redundant version
Communication to the DCS is established via RS-485 with Modbus RTU
Fieldbus termination can be activated at the RS-485 communication interfaces
Use of twisted, screened RS-485 copper cable in compliance with IEC 61158
Connection of the RS-485 communication cables via spring clamp terminals accessible
from the front side (hidden by hinged fold-out front doors)
Cross section of spring clamp terminals:
-
Single strand: 0.08 2.5 mm²
-
Fine stranded: 0.25 2.5 mm², with wire end sleeves up to 1.5 mm²
Configuration of the Modbus RTU communication parameters (baud rate, transmission
format, slave address) is made via the HMI user interface.
Supported baud rates: 0.3 115.2 kbit/s
Supported transmission formats: 8 data bits, 1 or 2 stop bits; parity: Even, Odd or None.
Supported Modbus function codes:
01 Read Coil Status
02 Read Input Status
03 Read Holding Registers
04 Read Input Registers
05 Force Single Coils
06 Preset Single Registers
15 (0x0F) Force Multiple Coils
16 (0x10) Preset Multiple Registers
08 Diagnostics
-
00 00 Loopback
-
00 10 (0AHex) Clear Counters and Diagnostic Register
-
00 11 (0BHex) Return Bus Message Count
-
00 12 (0CHex) Return Bus Communication Error Count
-
00 13 (0DHex) Return Bus Exception Error Count
-
00 14 (0EHex) Return Slave Message Count
-
00 15 (0FHex) Return Slave No Response Count
-
00 16 (10Hex) Return Slave NAK Count
-
00 17 (11Hex) Return Slave Busy Count
-
00 18 (12Hex) Return Character Overrun Count
Options:
Modbus TCP/IP in single-channel or redundant version
Communication via DCS is established via Ethernet, 10 Base-T or 100 Base-T (IEEE
802.3) using Modbus TCP/IP
Up to four simultaneous Modbus TCP/IP connections
10/100 Mbit/s
Configuration of the Modbus TCP/IP communication parameters (IP address and subnet
mask, port as well as Unit ID) is made via the HMI user interface.
Communication in Modbus data format via TCP/IP protocols
For redundant version: Connection to identical or to different subnets possible (option).
Supported Modbus function codes:
01 Read Coil Status
02 Read Input Status
03 Read Holding Registers
04 Read Input Registers
05 Force Single Coils
06 Preset Single Registers
15 (0x0F) Force Multiple Coils
16 (0x10) Preset Multiple Registers
34
SIMA² Master Station
Technical data MODBUS RTU, MODBUS TCP/IP to DCS
