AUMA SQ Series Manual

Descriptions referring to name plate indications
Type designation
Table 1:
Description of type designation (with the example of SQ 07.2-F10)
-F1007.2SQ
Type SQ = Part-turn actuators for open-close duty
Type SQR = Part-turn actuators for modulating duty
SQ
Size
These instructions apply to sizes 05.2, 07.2, 10.2, 12.2, 14.2
07.2
Flange sizeF10
Table 2:
Description of actuator controls type designation (with the example of AC 01.2)
01.2AC
Type AC = AUMATIC actuator controlsAC
Size 01.201.2
Order number
The product can be identified using this number and the technical data as well as
order-related data pertaining to the device can be requested.
Please always state this number for any product inquiries.
On the Internet at http://www.auma.com > Service & Support >myAUMA, we offer
a service allowing authorised users to download order-related documents such as
wiring diagrams and technical data (both in German and English), inspection certificate
and the operation instructions when entering the order number.
Serial number
Actuator
Table 3:
Description of serial number (example of 0520NS12345)
NS123452005
Positions 1+2: Assembly in week = week 0505
Positions 3+4:Year of manufacture = 202020
Internal number for unambiguous product identificationNS12345
Actuator terminal plan
Position 9 after TPA: Position transmitter version
I, Q = MWG (Magnetic limit and torque transmitter)
AUMA power class for
switchgear
The switchgear used in the actuator controls (reversing contactors/thyristors) are
classified according to AUMA power classes (e.g. A1, B1, ....).The power class
defines the max. permissible rated power (of the motor) the switchgear has been
designed for.The rated power (nominal power) of the actuator motor is indicated in
kW on the motor name plate. For the assignment of the AUMA power classes to the
nominal power of the motor types, refer to the separate electrical data sheets.
For switchgear without assignment to any power classes, the actuator controls name
plate does not indicate the power class but the max. rated power in kW.
Control
Table 4:
Control examples (indications on actuator controls name plate)
DescriptionInput signal
Control voltage 24/48/60 V DC for OPEN-CLOSE control via digital inputs
(OPEN, STOP, CLOSE)
24/48/60 V DC
Control voltage 100 – 125 V DC for OPEN-CLOSE control via digital inputs
(OPEN, STOP, CLOSE)
100 – 125 V DC
Control voltage 100 – 120 V AC for OPEN-CLOSE control via digital inputs
(OPEN, STOP, CLOSE)
100 – 120 V AC
Input current for setpoint control via analogue input0/4 – 20 mA
11
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Name plate
