AURATON 2020 - Technical specification

19. Technical specification
1. The range of temperature measurement
0÷40ºC (graduation 0.25ºC)
2. The range of temperature control
5÷27ºC (graduation 0.25ºC)
3. Accuracy of indication
+/-1ºC
4. Accuracy of the clock
± 70 seconds/per month
5. Programs
4 on working days, 2 on Saturday, 2 on Sunday
6. Sensitivity of temperature control
0.5ºC, 1ºC, or 2ºC
(adjusted in the factory to 1ºC)
7. Control mode
Heating
8. Admissible load of the terminals (*)
230V AC, 50Hz, 5A
9. Supply
2 R6 batteries, alkaline ones for the TX version
10. Dimensions
154´80´30mm (width´height´thickness)
11. Operating temperature
from 0 to 50ºC
12. Storage temperature
from -20 to 50ºC
14. Humidity conditions
from 5 to 90%
59
EN
AURATON 2020 TX RX Plus - Technical specification
