Auria EQ5588 - Component and Port Identification


Namesofeachpart

1 USB(Onlytoupdatethesoftware) 8 SPDIF
2 HDMI1jack 9 S‐VIDEO
3 HDMI2jack 10 AV2INandAUDIO2(R/L)
4 HDMI3jack 11 AV1INandAUDIO1(R/L)
5 PCandPCAUDIOjack 12 TV
6 Y2,Pb2,Pr2andAUDIO(R/L)jack 13 ACinput
7 Y1,Pb1,Pr1andAUDIO(R/L)jack  
Theproductcolorandshapemayvarydependingonthemodel.












