1. Robot
2. Plug collection and charging station
3. Mop holder
4. Mop
5. Dust collection tray
(dust collection station)
6. Side brush
7. Main brush cover
8. HEPA lter
9. Main brush
10. Water tank/dust collector
11. Cleaning comb
12. Dust bag handle
13. Dust bag
14. Auto charging/App connection
15. On/Off/Start/Stop button
16. Laser obstacle sensor
17. Laser distance sensor
18. System reset button
19. Dust collector cover
20. Release button
14
16
20
25 27
17
19
15
37
22
24
23
26
30
29
28
38
31
33
36
34
32
35
39
1.2.5 Front view of dust collection
and charging station
1.2.6 Bottom view of dust
collection and charging station
1.2.7 Top view of dust
collection and
charging station
21. Charging clamp
22. Side brush
23. Cliff sensor (Cliff detection at 9 cm)
24. Powered caster
25. Universal castor
26. Cliff sensor (Cliff detection on 9 cm)
27. Battery cover
28. Powered Castor
29. Main brush
30. Main brush cover
31. Dust collection station cover
32. Dust collection station
33. Indicator light dust collection
and charging station
34. Infrared lens
35. Charging clamp
36. Dust port
37. Dust tube cover
38. Dust tube
39. Fan lter
