Austro Engine E4P User Manual

Operation Manual
E4P
E4.01.02
Issue date: 15.Nov.2016
Page: 6-17
Revision no: 1
Failure description
Failure
Code
Caution
Indication
Caution
Latched
ECU Switch
Over
Main relay path 1 failure
1A01
YES
YES
YES
Main relay path 2 failure
1A02
YES
YES
YES
Main relay path 3 failure
1A03
YES
YES
YES
Engine oil pressure sensor failure
1B13
YES
YES
YES
Oil temperature sensor
2014
YES
YES
YES
Injection monitoring failure
2322
YES
YES
YES
Redundant engine speed monitoring failure
2343
YES
YES
YES
Rail pressure control valve, electric current
monitoring
2151
YES
YES
YES
Pressure control valve power stage failure
2500
YES
YES
YES
Pressure control valve power stage failure
2501
YES
YES
YES
Pressure control valve power stage failure
2502
YES
YES
YES
Propeller governor-actuator power stage
failure
1C02
YES
YES
YES
Propeller governor-actuator failure
1C03
YES
YES
YES
Propeller governor-actuator end stop switch
failure
1C04
YES
YES
YES
Electric fuel pump actuator failure
2100
YES
YES
YES
Common rail pressure sensor failure
190
YES
YES
YES
Test of redundant shut off paths
2122
YES
YES
YES
Sensor supply voltage 1 failure
1611
YES
YES
YES
Sensor supply voltage 2 failure
2306
YES
YES
YES
Sensor supply voltage 3 failure
2332
YES
YES
YES
Engine master switch signal failure
1612
YES
YES
YES
TPU monitoring failure
2342
YES
YES
YES
Voter relay failure
1D14
YES
YES
YES
Watchdog connection failure
2323
YES
YES
YES
Non-Latched Caution Indications
Failure description
Failure
Code
Caution
Indication
Caution
Latched
ECU Switch
Over
ECU XA connector failure
1D01
YES
NO
NO
ECU actuator connector failure
1D02
YES
NO
NO
ECU XB connector failure
1D03
YES
NO
NO
Cam shaft and crank shaft synchronisation
failure
2606
YES
NO
NO
Power lever position sensor 1 of ECU A and
B not consistent
1B01
YES
NO
NO
Power lever position sensor 2 of ECU A and
B not consistent
1B02
YES
NO
NO
Barometric air pressure sensing of ECU A
and B not consistent
1B03
YES
NO
NO
Boost pressure sensing of ECU A and B not
consistent
1B04
YES
NO
NO
Cam shaft speed sensing of ECU A and B not
consistent
1B05
YES
NO
NO
Crank shaft speed sensing of ECU A and B
not consistent
1B06
YES
NO
NO
