Austro Engine E4P User Manual

Operation Manual
E4P
E4.01.02
Issue date: 15.Nov.2016
Page: 6-19
Revision no: 1
Failure description
Failure
Code
Caution
Indication
Caution
Latched
ECU Switch
Over
Common rail, pressure control valve failure 1
2019
YES
NO
YES
Common rail, pressure control valve failure 2
2020
YES
NO
YES
Common rail, pressure control valve failure 3
2021
YES
NO
YES
Common rail, pressure control valve failure 4
2023
YES
NO
YES
Common rail, pressure control valve failure 5
2052
YES
NO
YES
ECU self test timeout failure
1D07
YES
NO
NO
Propeller self test failure
1C01
YES
NO
NO
Event: Fuel pressure operating range
1E13
YES
NO
YES
Boost pressure governor failure
2359
YES
NO
YES
Watchdog communication failure
2321
NO
NO
YES
Not indicated faults
Failure description
Failure
Code
Caution
Indication
Caution
Latched
ECU Switch
Over
Data logger failure
1E02
NO
NO
NO
Caution lamp power stage failure
1C11
NO
NO
NO
Record manager failure
1E01
NO
NO
NO
Real time clock failure
1D06
NO
NO
NO
Indicator: ECU self test is active
1D08
NO
NO
NO
Coolant temperature sensor failure *)
115
NO
NO
NO
Fuel temperature sensor failure *)
180
NO
NO
NO
Gearbox oil temperature sensor failure *)
1B11
NO
NO
NO
Default Values in case of a failure
Failure description
Failure
Code
Default Value
Effect on Engine
Performance
Engine power
display
Power lever sensor 1 failure
1222
Sensor 2 or if both fail 80%
No effect, or if both fail about
80% available ,
Correct
Power lever sensor 2 failure
1234
Sensor 1 or if both fail 80%
No effect, or if both fail about
80%,
Correct
Atmospheric pressure sensor failure
1105
800mbar
Limitation of the engine
Correct
Battery voltage failure
1615
24V
No effect
Correct
Boost pressure sensor failure
105
2600mbar
About 80%of the engine power
shall be available.
Deviates
Coolant temperature sensor failure *)
115
-20°C or 60°C depending on oil
temperature
No effect
Correct
ECU temperature sensor failure
2361
100°C
No effect
Correct
Fuel pressure sensor failure
2006
2,5bar
No effect
Correct
Fuel temperature sensor failure
180
21°C
No effect
Correct
Gearbox oil temperature sensor failure
*)
1B11
0°C (only in baseline 13 40°C)
No effect
Correct
Intake air temperature sensor failure
110
60°C
As stated in the Performance
Diagrams at 60°C Intake Air
Temperature
Deviates
Engine oil pressure sensor failure *)
1B13
0,03bar
No effect
Correct
Oil temperature sensor *)
2014
70°C
No effect
Correct
Common Rail pressure Sensor faiilure
190
Control Set Point
About 80%of the engine power
shall be available
Deviates
*) If the sensor is faulty an error value will by transmitted to the display instrument (e.g. Garmin G1000)
which marks the corresponding value as faulty.
