LIMITATIONS
RSUK0287_POH_Cavalon Revision 3.0, Issue Date 06.04.16 2-14
On keel tube fin (where fitted, both sides)
Circuit breakers
- Other
If the compass deviation is more than 5° on all headings, then a deviation placard
must be present.
The aircraft is fitted with a permanently attached fireproof plate with the aircraft registration
number and serial no. marked on it, on front of the instrument panel.
The registration letters are placed high on the tail fin, and are 60cm long, 30cm high. This
has been accepted as best practice compliance to CAP523, the CAA standard for aircraft
registration. Alternative markings and position of markings is acceptable provided they
comply with this standard.
Note that all placards must have the same units of measure as the instruments.
COMPASS DEVIATION
For N 30 60
Set
For E 120 150
Set
For S 210 240
Set
For W 300 330
Set
Calibration by: date:
