LIMITATIONS
RSUK0287_POH_Cavalon Revision 3.0, Issue Date 06.04.16 2-5
2.6 Powerplant Limitations and Instrument Markings
Engine Speed Marking
Maximum engine speed
Red radial
5800 RPM
5 minute take-off power regime Yellow arc 5500 – 5800 RPM
Maximum continuous power
Green arc
1400 –
5500 RPM
Recommended pre-rotation clutch speed
Green radial
2000 RPM*
Yellow arc 0 – 1400 RPM
Engine Oil Temperature Marking
Maximum oil temperature
Red radial
130 °C
Yellow arc 110 – 130 °C
Normal range
Green arc 90 – 110 °C
Yellow arc 50 – 90 °C
Minimum oil temperature
Red radial
50 °C
NOTE
Oil temperature is measured in the oil tank, and is the temperature of the oil as
it exits the engine. After the oil is cooled in the oil cooler, and returned to the
engine.
