SYSTEM DESCRIPTION
RSUK0287_POH_Cavalon Revision 3., Issue Date 06.04.16 7-11
aircraft console
powered from
“Heat” CB
Note that the external charging point permits charging via a Ctek charger
CAUTION
Do not reset CB’s in flight unless essential for continued safe flight
7.14 Avionics
Radio.
Option fit is the Funkwerk ATR500 radio for both external and internal communications. The
wiring harness terminates in a standard jack plug type connection at each seat, and the
antenna may be mounted inside the nose, or underneath the enclosure. Ensure the
headsets chosen function correctly before flight, and refer to the radio’s User Manual.
The radio EASA approval number is LBA.0.10.911/113JTSO
Optionally a Funkwerk ATR833 may be fitted, approval no EASA.21O.0193
Transponder.
Option fit is a Funkwerk TRT800H Mode S transponder. The antenna protrudes under the
body. Read the User Manual for operational instructions, and take care that the Mode S
hexadecimal code and aircraft recognition data is correct!
The Funkwerk TRT 800H carries an EASA approval, approval no. EASA.210.269
Remark; A Radio Operators licence is required to allow use of the radio, and a Radio
Installation licence is required for the radio and transponder (one combined licence,
renewed annually).
