AutoGyro Calidus - Control and System Placards; Fuel Cut-Off Valve and Ignition Switches

RSUK0060_POH_CD Revision 7.0, Issue Date17.01.2019 10
Day VMC Only. Do not rely on this display.
Fuel cut-off valve Interlock placard (unless engraved on
panel)
Placard above switch, where fitted, for Airbox GPS (adjacent to ‘Nav’ sw). ‘Off’ placard is
fitted below the switch.
Where a Flymap L GPS has been fitted with an AHRS unit, the following placard must be
affixed adjacent to the Flymap GPS.
Instructor pack (where fitted). Brake placard only where brake is fitted.
Off
On
Fuel cut-off
valve
Pre
-
rotator &
rotor brake
interlock
release
GPS
OFF
Ignition cut off
switches.
To switch off, lift
safety flaps and
pull toggles
backwards.
MAX
↑
THROTTLE
BRAKE
↓
ENGAGE
