Calidus
SYSTEM DESCRIPTION
AutoGyro_POH_Calidus Revision 4.0 – Issue Date 17.JAN.2019 7-27
7.19 Stowage Capacity
Two storage compartments are located below each seat with a maximum capacity of 2.5 kg
each (2.0Kg UK).
7.20 Fire Warning System
The Calidus gyroplane may be equipped with a Fire indicator light to alert the pilot that a
certain temperature in the engine compartment has been exceeded, possibly as a result of
a fire. The fire indication circuit is based on a special cable routed inside the
compartment(s). The cable has two integrated wires separated by an insulation layer. At a
defined temperature the insulation layer will melt and the embedded wires close contact.
A possible fire (circuit closed with low resistance) will be indicated by a flashing/blinking Fire
indicator light in the Warning and Caution Panel. During normal operation (circuit closed
with ‘normal’ resistance) the Fire indicator light will be off. A malfunction of the system
(circuit open or shorted to ground) is indicated by a constantly lit Fire indication. At every
power-on event the system will perform a lamp test consisting of a series of three flashes.
OFF Normal Operation (normal resistance)
FLASHING Fire, abnormal temperature (circuit closed)
ON System Malfunction (circuit open or shorted to ground)
In the event of a fire indication being shown, proceed according to emergency procedure
“Smoke and Fire” provided in SECTION 3.
7.21 Fuses
Fuse
description
Rating Protects Fuse type Location
Main incoming
supply to
cockpit
30A ETFE
40A PVC
Main positive
supply is fed to
the starter
solenoid from the
battery. The
supply continues
then through the
30amp fuse to the
cabin.
Bolt in strip
type, MTA
S.p.A.
“Midival”
range
Engine bay fuse
box, above left
fuel tank, on rear
face of enclosure
or engine bearer.
Compressor 10A Fuse only supplies
the pneumatic
compressor
Automotive Inst. Panel
Primary Fuel
pump
(replaced by
5A Fuel pump Automotive Inst. Panel
