AutoGyro Calidus - Rate of Climb and Take-off;Landing Data

Pilot Operating Handbook
Calidus
SECTION 5
PERFORMANCE
AutoGyro_POH_Calidus Revision 4.0 – Issue Date 17.JAN.2019 5-4
Min horiz speed (Vmin), TOP (ROTAX 914)*, 560Kg ........ 55 km/h (35mph) IAS
Min horizontal speed (Vmin), TOP (912), 500Kg............... 55 km/h (35mph) IAS
Speed for best angle of climb V
X
.......................... 100 -110km/h (60-70mph)IAS
Speed for best rate of climb or maximum endurance V
Y
... 90 km/h (55mph) IAS
Best range speed ........................................................... 130 km/h (80mph) IAS
Long range speed***....................................................... 140 km/h (87mph) IAS
Vmc power-off****............................................................. 32 km/h (20mph) IAS
Vmc power on****................................................................. 0 km/h (0mph) IAS
* Take care! A full power operation at Vmin (especially at a low TOW) with a
Rotax 914UL will result in a very high nose-up attitude with little forward
visibility.
** Long range speed is the speed faster than the best range speed which
results in a slightly lesser range but represents a good compromise between
range and saved air time.
*** Approach speed above 60mph builds energy in the rotor that results in a
long floating landing. Approach speed at 50mph results in a very short
landing roll, and below 50mph requires increasing skill especially at
maxTOW.
****Vmc is the minimum controllability speed. At 20mph or below, engine off,
rudder authority reduces, to negligible below 10mph.
TOP is Take Off Power
5.5 Rate of Climb
2
Rate of climb, 500 kg, V
Y
, TOP, 914UL....................................3.6 m/s (700fpm)
Rate of climb, 560 kg, V
Y
, TOP, 914UL....................................2.8 m/s (550fpm)
Rate of climb, 500 kg, V
Y
, TOP, 912ULS .................................2.5 m/s (500fpm)
Rate of climb, 500 kg, V
Y
, MCP ...............................................3.4 m/s (660fpm)
Rate of climb, 450 kg, V
Y
, MCP ..................................................4 m/s (780fpm)
Rate of climb, 360 kg, V
Y
, MCP ................................................6 m/s (1170fpm)
5.6 Take-off and Landing Data
Take-offs and landings have been demonstrated up to a crosswind component of 36 km/h.
The following data is valid for operation at a gross mass of 450 kg at an even air strip with
short grass, no wind, and pre-rotation to 220 RPM. Take-off and landing distances account
for a 15m obstacle.
Take-off roll*.....................................................................................80 – 120 m
Take-off distance*......................................................................... 300 m (975ft)
* Take-off roll and take-off distance will be shorter using the boost regime of
the ROTAX 914 engine
2
Rate of Climb values were identified within noise measurement according to German
regulations and may differ from the listed values depending on engine and propeller type.
