RSUK0060_POH_CD Revision 7.0, Issue Date17.01.2019 6
face whilst measuring (see Maint. Manual RSUK0061). Propeller is pitched for max ground
rpm of 5500.
For the Ivoprop DL3-68, refer to manual RSUK0325.
9.
GENERAL PLACARDS AND MARKINGS:
In conformity with BCAR Section T the following placards and markings are installed:
- All emergency controls are coloured red.
- All cockpit controls are clearly marked as to their function and method of operation.
- Fuel and oil filler openings are clearly marked, together with the grade or type required.
- Fuel tank capacity is clearly marked.
- Loading conditions are clearly marked as follows:
Loading conditions. This may indicate an MTOW of 500 or 560Kg
Throttle, choke and brake control marking
Limitations if fitted with orange end-cap rotor system
Aircraft Payload Specification
Front seat pilot: 125Kg max, 65Kg min
Pilot must carry ballast to meet 65Kg min.
Rear seat passenger 120Kg max
Empty weight (as measured) Kg
MTOW 500Kg
Aircraft must only be flown solo from the front
seat.
↑
THROTTLE
↓
ON
BRAKE
↓
Aerobatic Limitations
Aerobatic manoeuvres are prohibited.
Manoeuvres involving a deliberate reduction in normal ‘g’ shall be avoided.
CG Range Limits (Gyroplane) – refer to Pilots Handbook data.
Airspeed Limitations
Maximum Indicated Airspeed (Vne): 90mph
Other Limitations
This aircraft shall be flown by day and under Visual Flight Rules only.
Smoking in the aircraft is prohibited
