3. Specifications
Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Maximum door opening:
Width:
Height:
Weight:
5500mm (13.5m
2
)
2440mm
100kg
Minimum headroom 25mm
Short Term Peak Force 650N (65kg)
Rated force 400N (40kg) with Chain
Nominal force 150N (15kg)
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 8 X 4 button Transmitter Codes
Transmitter frequency 433.47, 433.92, 434.37MHz
Coding type TrioCode
TM
128 Type
Number of code combinations Over 100 billion random codes
Code generation Non-linear encryption algorithm
Transmitter battery CR2032 (3 Volts)
Courtesy light Festoon style lamp 24volts 15 watts
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind
puts extra pressure on the door and tracks which may in turn intermittently trigger the safety obstruction
detection system.
