2 HIRO Installation Manual GDO-12V1
Contents
1. System Specifications 3
2. Safety Information 4
3. Sécurité 5
4. Kit Contents 6
5. Operator Safety & Security 7
5.1 Your Door CAN NOT be used by the opener when: 7
5.2 Your Door CAN be used when: 7
5.3 To Disengage the Opener: 7
5.4 To Re-Engage the Opener: 7
6. Installation Instructions 8
6.1 Pre-Installation Requirements 9
6.1.1 Door Operation 9
6.1.2 Unsuitable Door Types 9
6.1.3 Position 9
6.1.4 Power Supply 9
6.1.5 Sideroom 9
6.1.6 Forks 9
6.2 Door Preparation 10
6.2.1 Preparation 10
6.2.2 Pinning the Door to the drum: 10
6.2.3 Door prop preparation 10
6.3 Fitting the Opener 11
6.4 Safety Beam Installation 12
6.4.1 Safety Infra-Red Beam Kit (P/N 62047) 12
6.4.2 Assembling the Mounting Bracket 12
6.4.3 Aligning the Transmitter and receiver 12
6.5 Setting Speed and Limits 13
6.5.1 Set the Limit Positions and adjust drive speed: 13
6.5.2 Clearing the Door Limit Positions 14
6.5.3 Re-profiling the Door 14
6.6 Auto-Close 14
6.7 Safety Testing & Accessories 15
6.7.1 Testing the Close Cycle 15
6.7.2 Testing the Open Cycle 15
6.7.3 Installation of Premium Wall Control 15
6.8 Coding Transmitters 16
6.8.1 Remote Control Transmitter Button to Operate Door 17
6.8.2 Erasing Programmed Codes 17
6.8.3 Selecting The Function To Be Coded 17
6.8.4 Installing a wall button control 17
6.9 Attach Warning Labels 18
7. Operation Instructions 19
7.1 How to Use Your Operator 20
7.1.1 To Operate the opener: 20
7.1.2 Replacing the Battery: 3V Lithium Battery CR2032. 20
7.2 User Operating Controls 21
7.3 Door Status Indicators 21
7.4 Disposal of Batteries 22
8. User Maintenance Instruction 23
8.1 Door Maintenance 23
8.2 If You Need a Service Call 23
9. Troubleshooting 24
10. Appendix 25
A - Adjustment Mode Parameters 25
B - Setting the PET Mode position 26
C - LED Status 26
D - Setting Limits via Transmitter 27
E - Additional Remote Control Functions 28
GDO-12
HiR
High Roll Up Garage Door Opener
