Installation Instructions MegaCode
®
Receiver 11
Fig 6.1
Fig 6.3
Menu 7.3 Settings
Under this menu, four sub menus are available:
i. Run Programs. This parameter allows the User to halt both
run the timer programs. The programs of the timer can be
interrupted by selecting RUN PROGRAM off.
ii. Disable 4 Input. This input can be used as a daylight saving
time adjuster. When activated, it will add the amount of time
selected in Menu 7.3.4 (7.3.iv) to the Time Clock
iii. Disable 4 Input Contact. Disable four (4) input is configured
for N/O operation. This parameter allows its operation to be
changed to N/C.
iv. Daylight Saving Time Adjust. The amount of time to add to
the time clock at start of daylight saving period is selected
here. Options are OFF, 30, 60, 90 or 120 minutes.
Technical Specifications
Power supply 12 - 24V AC/DC
Number of Outputs Four (4)
Continuous Load Current per Output 100mA @ 40 VDC
Transmitter Type TrioCode
TM
128 or Tri-Tran
+TM
type
Receiver code storage capacity 511 x 4 button Transmitter Codes
7. Specifications
Symptom Possible cause Remedy
Opener will not operate Wiring to Outputs / Inputs
incorrect.
The Disable input is activated
The opener is in “Vacation Mode”
Check wiring.
Deactivate the disable input
Turn off “Vacation Mode”(Appendix A Menu 6.8).
LCD not working Mains power not switch on. Switch on mains power..
Opener does not work from
transmitter
Transmitter code not stored in
receiver.
Code transmitter in to receciver.
(Section 4.1)
Transmitter does not contain
TrioCode™128 Technology
Check the transmitter. It should have grey buttons
and the model number should display V2. Contact
dealer for support if otherwise.
Flat battery in transmitter Replace battery (Section 5.3)
Programs not activating Time Clock Program not set.
Time Clock battery flat.
Check settings (Section 6.2) and adjust accordingly
Replace Time Clock battery (Section 6.3)
8. Troubleshooting
6.3 Removing the Time Clock Battery From the Receiver
(Battery Type: 3V Lithium Battery CR1220).
Use a non-metallic object (e.g. pen) to remove the battery. (Fig. 6.4).
