Automation Technology C2 Series Hardware Reference Manual

16 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
Name Rev. Interface Access Description
ReverseY 1.0
IBoolean R/W When set to true, this parameter flips the sensor
image vertically.
OffsetX 1.0 IInteger R
X Offset of AOI (fixed to zero)
TestImageSelector 1.0
IEnumeration R/W Selection of the test image to be used.
- Off
- GreySensorColumnPattern
LinePitch 1.0
IInteger R Distance between consecutive lines in bytes.
PixelDynamicRangeMin 1.0
IInteger R Minimum pixel value sent by the camera.
PixelDynamicRangeMax 1.0
IInteger R Maximum pixel value sent by the camera.
AcquisitionControl
Name Rev. Interface Access Description
AcquisitionStart 1.0 ICommand W Issues the START command. This starts the
acquisition.
AcquisitionStop 1.0 ICommand W Issues the STOP command. This stops the
acquisition.
AcquisitionMode 1.0 IEnumeration R/W Defines the type of acquisition:
- SingleFrame
- MultiFrame
- Continuous
AcquisitionAbort 1.0 ICommand W Issues the ABORT command. This immediately
aborts the acquisition without completing the current
frame.
AcquisitionFrameCount 1.0 IInteger R/W Number of frames to be acquired in MultiFrame
acquisition mode. The minimum allowable value is 1.
AcquisitionFrameRateAbs 1.2 IFloat R The frame rate of the imager. Absolute units are in
Hz.
AcquisitionStatusSelector 1.2
IEnumeration R/W Selector for AcquisitionStatus to read:
- AcquisitionTriggerWait
- AcquisitionActive
- AcquisitionTransfer
- FrameTriggerWait
AcquisitionStatus[AcquisitionStatus
Selector]
1.2
IBoolean R Status of the selected acquisition flag
AcquisitionMaxBufferedFrameCoun
t
AT IInteger R Maximum number of buffered frames
ExposureMode 2.2 IEnumeration R Sets the operation mode of the exposure:
1 : Timed
2 : MultiSloped
3 : MultiExposed
MultiSloped and MultiExposed refers to HDR-3D
ExposureTime 2.2 IInteger R/W Sets the overall exposure time when ExposureMode
is Timed or MultiSloped in microseconds (µs).
This parameter is the standardized equivalent to
ExposureTimeAbs
ExposureSlopeKneepointCount AT IInteger R/W The number of additional exposure slopes used for
Multi-Slope exposure
0: SingleSlope
1: DualSlope
2: TripleSlope
ExposureSlopeKneePointSelector AT IInteger R/W Selects the parameters for controlling a kneepoint
during multi-slope exposure
ExposureSlopeDuration AT IFloat R/W The exposure duration (in percentage of
ExposureTime) for determining a kneepoint during
multi-slope exposure
ExposureSlopeThreshold AT IFloat R/W The threshold for determining a kneepoint during
multi-slope exposure. Setting this value to 100% will
effectively disable this kneepoint
