Automation Technology C2 Series Hardware Reference Manual

8 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
The C2-2040(HS)-GigE Camera General Specifications
Camera Controls
Synchronization Modes Free running, Triggered, Software Triggered
Exposure Modes Programmable, Pulse controlled
Shutter Modes Global Shutter
Digital Trigger Input 2 inputs, 5 V
VIL, logic “0” Voltage < 1.5 V
VIH, logic “1” Voltage > 3.5 V
Digital Output 2 outputs
VOL, logic “0” Voltage < 0.5 V
VOH, logic “1” Voltage ≥ 4.5 V
IOH, logic “1” output current 20 mA
IOL, logic “0” output current 20 mA
Features
3D-Algorithms MAX, TRSH, COG, FIR PEAK
High Speed Acquisition Full frame: 340 fps
High Dynamic Range Imaging Multiple Slope, Multi-Frame Readout
Multiple AOIs / Laser lines Up to 8
Optical Interface
Lens Mount C-Mount with Back Focal Distance 17.526 mm
Mechanical Interface
Camera Size 44 mm x 44 mm x 66 mm
Mass (without optics) 125 g
Power connector 17 pin, M12 connector
Ethernet connector 8 pin, A-coded M12 connector
Electrical Interface
Input Voltage 10 – 24 V DC (max. 27 V DC)
Power consumption < 6 W
Operating Temperature 0 °C to +50 °C (non condensing)
Output Data Interface Gigabit Ethernet (IEEE 802.3)
Communication Protocol GigE Vision with GeniCam
