Automation Technology C2 Series Hardware Reference Manual

C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 25
The GenICam Features Configuration of C2-2040(HS)-
GigE
Due to dependencies of the XML nodes of C2-2040(HS)-GigE registers, it is recommended to follow a
specific order, when configuring the GenICam features of the camera. The list shown below,
generated as a CXC file by the CX-Explorer, demonstrates an example of the correct write order:
CameraMode CenterOfGravity
ProfileTriggerMode FreeRun
EnableDC2 1
EnableDC1 0
TestImageSelector Off
ReverseX 0
PixelFormat Mono16
ReverseY 0
DeviceTemperatureSelector Mainboard
AcquisitionMode Continuous
AcquisitionFrameCount 1
CameraMode CenterOfGravity
ProfilesPerFrame 1000
ClearInvalidPos 0
PosValidationEn 0
AbsOffsetPos 0
TrshFirstFalling 0
NumSubPixel 6
ValidationWidthMin 0
ValidationWidthMax 1087
ValidationSumMin 0
ValidationSumMax 65535
AoiTrackingEnable 0
AoiTracking_P 0.65
AoiTracking_I 0.5
AoiTracking_D 0.12
AoiTrackingUpdateRate 100
AoiTrackingSensorWriteTimeout 10000
AoiTrackingMinNumPixel 100
AoiSearchEnable 0
AoiSearchHeight 1088
AoiSearchOffsetY 0
ColRangeStart 0
ColRangeEnd 2047
NumAois 1
AoiSelector 1
AoiHeight 1088
AoiOffsetY 0
AoiThreshold 120
FIR 0
ExposureTimeAbs 100
FramePeriod 2958
MultipleSlopeMode SingleSlope
NDRMode Off
GainPGA Gain2
GainADC 40
