18 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
Name Rev. Interface Access Description
ValidationWidthMax AT IInteger R/W Maximum width of valid intensity distribution in 3D-
mode.
ValidationSumMin AT IInteger R/W Minimum sum of intensity of valid intensity
distribution in 3D-mode.
ValidationSumMax AT IInteger R/W Maximum sum of intensity of valid intensity
distribution in 3D-mode.
CameraControl – ModeAndAlgorithmControl - AoiTracking
Name Rev. Interface Access Description
AoiTrackingEnable AT IBoolean R/W True: AOI-Tracking mode is enabled
False: AOI-Tracking mode is disabled
AoiTrackingMinNumPixel AT IInteger R/W Minimum number of required pixel (one pixel per
column) to start AOI tracking algorithm
AoiTracking_P AT IFloat R/W Proportional gain of PID controller
AoiTracking_I AT IFloat R/W Integral gain of PID controller
AoiTracking_D AT IFloat R/W Derivative gain of PID controller
AoiTrackingUpdateRate AT IInteger R/W Update frequency of tracking algorithm (Hz)
AoiTrackingSensorWriteTimeout AT IInteger R/W AOI tracking senosr write timeout in microseconds
(µs)
CameraControl – ModeAndAlgorithmControl - AoiSearch
Name Rev. Interface Access Description
AoiSearchEnable AT IBoolean R/W True: AOI-Search mode is activated
False: AOI-Search mode is disabled
AoiSearchHeight AT IInteger R/W Height of search AOI
AoiSearchOffsetY AT IInteger R/W Vertical offset from the origin to the search AOI
CameraControl – ModeAndAlgorithmControl - ColumnEvaluationMask
Name Rev. Interface Access Description
ColRangeStart AT IInteger R/W Column start index
ColRangeEnd AT IInteger R/W Column end index
ColRangeEnableCommand
AT ICommand W Enable all columns from RangeStart to RangeEnd
ColRangeDisableCommand AT ICommand W Disable all columns from RangeStart to RangeEnd
ColRangeActivate AT ICommand W Activate complete ColumnEvaluationMask and write
data into flash memory
CameraControl – SensorControl
Name Rev. Interface Access Description
SensorFrameCounter AT IInteger R Sensor frame counter.
SensorReadoutTime AT IInteger R Sensor Readout Time in µs.
ExposureTimeAbs AT IInteger R/W Sensor integration time in µs.
FramePeriode AT IInteger R/W Time between two frames in µs.
FrameRate AT IFloat R Frame rate in Hz
ExposureMode AT IEnumeration R Sensor exposure mode:
- Interleaved (the sensor integration and readout
are performed in parallel).
MultipleSlopeMode AT IEnumeration R/W MultipleSlope Mode:
- SingleSlope
- DualSlope
- TripleSlope
DualSlopeTime AT IInteger R/W DualSlopeTime in % of sensor integration time
TripleSlopeTime AT IInteger R/W TripleSlopeTime in % of sensor integration time
NumberOfNDRFrames AT IInteger R/W Number of NDR frames.
NDRMode AT IEnumeration R/W Multi-Frame Readout Mode (NDR):
- Off
- On
NDRExposureTimeAbs_1 AT IInteger R/W NDR exposure time 1.
NDRExposureTimeAbs_2 AT IInteger R/W NDR exposure time 2.
NDRExposureTimeAbs_3 AT IInteger R/W NDR exposure time 3.
NDRExposureTimeAbs_4 AT IInteger R/W NDR exposure time 4.
