Automation Technology C2 Series Hardware Reference Manual

38 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
The Data Output Format of C2-2040(HS)-GigE
The image and 3D data output is performed by selecting the data channel DC0-DC2 (node Camera Controls→DataOutput). Depending on the
algorithm the data can be acquired by enabling the corresponding output Data Channel (DC). Every DC is saved in a new image row. The bit depth of
output data depends on the selected algorithm. In 3D mode the camera outputs data with 16 bit. In Image mode the camera can output 8 or 16 bit
data. When in 8 bit Image mode, the DC0 delivers the 8 most significant bits of the 10 bit intensity data.
The Data Channel Assignment DC0, DC1 and DC2
Camera Mode FIR FIRMode DC0 DC1 DC2
Image False - Sensor intensity Not used Not used
True
Derivative
First derivative of sensor intensity Not used Not used
True
Smoothing
Smoothed sensor intensity Not used Not used
MaximumIntensity
False - Maximum intensity of Gauss Position of rising edge of Gauss (PosL) Position of maximum intensity of Gauss
(PosM)
True
Smoothing
Maximum intensity of Gauss detected in
smoothed sensor image
Position of rising edge of Gauss (PosL)
detected in smoothed sensor image
Position of maximum intensity of Gauss
(PosM) detected in smoothed sensor
Threshold
False - Maximum intensity of Gauss - Position of rising edge of Gauss
(PosL)
or
- Gauss width (PosR-PosL)
- Position of falling edge of Gauss
(PosR)
or
- Position of Gauss with 1/2 pixel
resolution (PosL+PosR)
True
Smoothing
Maximum intensity of Gauss detected in
smoothed sensor image
- Position of rising edge of Gauss
(PosL)
or
- Gauss width (PosR-PosL) detected in
smoothed sensor image
- Position of falling edge of Gauss
(PosR)
or
- Position of Gauss with 1/2 pixel
resolution (PosL+PosR) detected in
smoothed sensor image
