Automation Technology C2 Series Hardware Reference Manual

22 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
Name Rev. Interface Access Description
GevVersionMajor 1.2 IInteger
R This field represents the major version of the GigE
Vision specification supported by this device
GevVersionMinor 1.2 IInteger
R This field represents the minor version of the GigE
Vision specification supported by this device
GevDeviceModeIsBigEndian 1.2
IBoolean R This represents the endianess of bootstrap registers
(FALSE: Little-endian device TRUE: Big-endian
device)
GevDeviceModeCharacterSet 1.2
IEnumeration R This feature represents the character set of all boot
strap strings:
- CharacterSet_UTF8
GevInterfaceSelector 1.2
IEnumeration R Indicates the index of the network interface to
configure:
- EnumEntry_GevInterfaceSelector_Interface_0
GevMACAddress 1.2
IInteger R 48-bit MAC address of the selected interface
GevSupportedIPConfigurationLLA 1.2
IBoolean
R/W Indicate if LLA (Auto-IP) is supported by the selected
interface
GevSupportedIPConfigurationDHC
P
1.2
IBoolean
R/W Indicate if DHCP is supported by the selected
interface
GevSupportedIPConfigurationPers
istentIP
1.2
IBoolean
R/W Indicate if Persistent IP is supported by the selected
interface
GevCurrentIPConfigurationLLA 1.2
IBoolean
R This feature indicates if Link Local Address IP
configuration scheme is activated on the given
network interface
GevCurrentIPConfigurationDHCP 1.2
IBoolean
R This feature indicates if DHCP Address IP
configuration scheme is activated on the given
network interface
GevCurrentIPConfigurationPersist
entIP
1.2
IBoolean
R This feature indicates if PersistentIP IP configuration
scheme is activated on the given network interface
GevCurrentIPAddress 1.2
IInteger R IP address of the selected interface
GevCurrentSubnetMask 1.2
IInteger R Subnet mask of the selected interface
GevCurrentDefaultGateway 1.2
IInteger R Default gateway of the selected interface
GevPersistentIPAddress 1.2
IInteger R/W Persistent IP address for the selected interface
GevPersistentSubnetMask 1.2
IInteger R/W Persistent subnet mask for the selected interface
GevPersistentDefaultGateway 1.2
IInteger R/W Persistent default gateway for the selected interface
GevLinkSpeed 1.2 IInteger R Link speed in Mbps.
GevFirstURL 1.2
IString R NULL-terminated string providing the first URL to the
XML device description file
GevSecondURL 1.2
IString R
NULL-terminated string providing the second URL to
the XML device description file
GevNumberOfInterfaces 1.2
IInteger R
Indicates the number of physical network interfaces on
this device
GevMessageChannelCount 1.2
IInteger R
Indicates the number of message channels supported
by this device
GevStreamChannelCount 1.2
IInteger R
Indicates the number of stream channels supported by
this device
GevSupportedOptionalCommands
UserDefinedName
1.2
IBoolean
R
Indicates if the User-defined Name register is
supported
GevSupportedOptionalCommands
SerialNumber
1.2
IBoolean
R
Indicates if the Serial Number register is supported
GevSupportedOptionalCommands
EVENTDATA
1.2
IBoolean
R
Indicates if EVENTDATA_CMD and
EVENTDATA_ACK are supported
GevSupportedOptionalCommands
EVENT
1.2
IBoolean
R
Indicates if EVENT_CMD and EVENT_ACK are
supported
GevSupportedOptionalCommands
PACKETRESEND
1.2 IBoolean
R
Indicates if PACKETRESEND_CMD is supported
GevSupportedOptionalCommands
WRITEMEM
1.2
IBoolean
R
Indicates if WRITEMEM_CMD and WRITEMEM_ACK
are supported
GevSupportedOptionalCommands
Concatenation
1.2
IBoolean
R
Indicates if multiple operations in a single message
are supported
GevHeartbeatTimeout 1.2
IInteger R/W
Current heartbeat timeout in milliseconds
GevTimestampTickFrequency 1.2
IInteger R
64-bit value indicating the number of timestamp clock
tick in 1 second
GevTimestampControlLatch 1.2
ICommand
R
Latches the current timestamp value of the device
GevTimestampControlReset 1.2
ICommand
R
Resets the timestamp count of the device
GevTimestampValue 1.2 IInteger R Latched 64-bit value of the timestamp. Value must first
be latched using GevTimestampControlLatch.
GevStreamChannelSelector 1.2
IInteger
R/W
Indicate which stream channel to configure
GevSCPInterfaceIndex 1.2
IInteger
R
Index of network interface
GevSCPSPacketSize 1.2
IInteger
R/W
The size of the stream packet to send on this channel
GevSCPD 1.2
IInteger
R/W
Delay (in timestamp counter unit) to insert between
