Autonics CX Series User Manual

2 Specifications
20 © Copyright Reserved Autonics Co., Ltd.
Series
CXS
CXM
Model
CX6S-1P□□
CX6S-2P□□ CX6M-1P□□ CX6M-2P□□
Input
method
CX6□-□□
Selectable among voltage input (PNP) / no-voltage input (NPN)
[Voltage input (PNP)] – input impedance: 10.8kΩ,
[H]: 5-30VDCЗ, [L]: 0-2VDC
[No-voltage input (NPN)] - short-circuit impedance: max. 1kΩ
short-circuit residual voltage: max. 2VDC
CX6□-□□F
[Free voltage input] – INA (START), INB (INHIBIT) input
[H]: 24-240VDCЗ/24-240VACЖ 50/60Hz,
[L]: 0-10VDC/VAC
[No-voltage input] - RESET input
short-circuit impedance: max. 1kΩ,
short-circuit residual voltage: max. 2V
One-shot output time 0.01 to 99.99s setting
Control
output
Contact
Type SPDT (1c): 1 SPST (1a): 2 SPDT (1c): 1 SPDT (1c): 2
Capacity Max. 250VACЖ 3A, 30VDCЗ 3A resistive load
Solid
state
Type
-
NPN open
collector: 1
NPN open collector:
2
Capacity Max. 30VDCЗ 100mA
External power supply
※1
Max. 12VDCЗ ±10%, 100mA
Memory retention Approx. 10 years (non-volatile memory)
Insulation resistance
Over 100MΩ (at 500VDC megger)
Dielectric strength 3,000VAC 50/60Hz for 1 min
Noise immunity
AC voltage
Square-wave noise by noise simulator (pulse width 1µs) ±2kV
AC/DC voltage
Square-wave noise by noise simulator (pulse width 1µs) ±500V
Vibration
Mechanical
0.75mm amplitude at frequency 10 to 55Hz (for 1 min) in each X, Y, Z
direction for 1 hour
Malfunction
0.5mm amplitude at frequency 10 to 55Hz (for 1 min) in each X, Y, Z direction
for 10 minutes
Shock
Mechanical
300m/s² (approx. 30G) in each X, Y, Z direction for 3 times
Malfunction
100m/s² (approx. 10G) in each X, Y, Z direction for 3 times
Relay life cycle
Mechanical Min. 5,000,000 operations
Malfunction Min. 100,000 operations
Protection structure Front part: IP50 (IEC standard)
Environment
Ambient temp. -10 to 55℃, storage: -25 to 65℃
Ambient humi. 35 to 85%RH, storage: 35 to 85%RH
Approval
Weight
※2
AC
voltage
CX6□-□□
Approx. 157g
(approx. 112g)
Approx. 162g
(approx. 117g)
Approx. 235g
(approx. 170g)
Approx. 240g
(approx. 175g)
CX6□-□□F
Approx. 155g
(approx. 110g)
Approx. 160g
(approx. 115g)
Approx. 233g
(approx. 168g)
Approx. 238g
(approx. 173g)
AC/DC
voltage
CX6□-□□
Approx. 156g
(approx. 111g)
Approx. 161g
(approx. 116g)
Approx. 234g
(approx. 169g)
Approx. 239g
(approx. 174g)
CX6□-□□F
Approx. 154g
(approx. 109g)
Approx. 159g
(approx. 114g)
Approx. 232g
(approx. 167g)
Approx. 237g
(approx. 172g)
