Autonics CX Series User Manual

5 Counter mode
© Copyright Reserved Autonics Co., Ltd. 41
5.2.1 Counter/Timer
Select operation type as counter or timer.
※Right after the selecting counter/timer, the below parameters are changes as the dedicated
operation.
5.2.2 Input mode
Select one counter input mode; up input [UP, UP-1, UP-2, UP-3], down input [DN, DN-1, DN-2,
DN-3], command input [UD-A], individual input [UD-B]
※
1
, phase-difference input [UD-C]
※
1
.
※1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6□-□□).
5.2.3 Output mode
Select one counter output mode; F, N, C, R, K, P, Q, A, S, T, D mode.
※In case of input mode UD-A, UD-B
※
1
, UD-C
※
1
, output mode S, T, D setting is available.
※When max. counting speed is set as 5kpcs, and output mode is D, max. counting speed is
changed as 30cps automatically.
※1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6□-□□).
5.2.4 Max. counting speed
Select one max. counting speed of INA, INB; 1cps, 30cps, 300cps, 1kcps, 5kcps.
※In case of D output mode, select one; 1cps, 30cps, 300cps, 1kcps.
5.2.5 OUT2 output time
Set one-shot output time of OUT2 output. (unit: sec)
※Setting range: 00.01 to 99.99s
 key: Moves the setting digits of output time value.
 key: Changes the flashing digit value.
※In case of 1-stage setting model(CX6
□-1P□□), OUT1output time does not appear.
OUT2 output time is displayed as OUtT.
※In case of F, N, S, T, D output mode, OUT2 does not appear. (fixed as HOLD)
