6 Timer mode
62 © Copyright Reserved Autonics Co., Ltd.
1: This is for the voltage input(PNP)/no-voltage input(NPN) selectable model (CX6-□□).
2: INt2 mode is available only for 2-stage setting model (CX6-2P□□).
3: When output mode is OND, ONd1, ONd2, ONd3, FLk1, FLk2, INT, INt1, INt2, OFD,
INTG, TOTAL, ONtD, set time range [tRNG].
4: When output mode is FLK, NFD, NFd1, set output ON time range [OnRNG] and
output OFF time range [OFfRNG].
5: In case of 1-stage setting model(CX6-1P□□), OUT1output time does not appear. OUT2
output time is displayed as OUtT.
6: In case of free voltage input model (CX6-□□F), this parameter does not appear due to
fixed setting.
