Autonics TK Series User Manual For Communication

Autonics 2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 19
No(Address)
Classification
Description
Unit
Value
Note
31001(03E8) PV Present Value
-1999 ~ 9999
℃/℉/- -
31002(03E9) - Decimal point location
0: 0 1: )0 2: )00 3: )000
- -
31003(03EA) - Indicator Unit
0: ?C 1: ?F 2: ?/O 3: OFF
- -
31004(03EB)
SV
SV Setting Value
Range from L-SV ~ H-SV
℃/℉/-
0000
31005(03EC)
H-MV
Heating Side MV
0~1000: H )0~H100
% -
31006(03ED)
C-MV
Cooling Side MV
0~1000: C )0 ~ C100
% -
31007(03EE)
℃ Indicator Unit Indicator
0: OFF 1: ON
- - Bit 0
℉ Indicator Unit Indicator
0: OFF 1: ON
- - Bit 1
% Indicator Unit Indicator
0: OFF 1: ON
- - Bit 2
OUT1 Indicator Control Output 1 Indicator
0: OFF 1: ON
- - Bit 3
OUT2 Indicator Control Output 2 Indicator
0: OFF 1: ON
- - Bit 4
AT Indicator Auto-tuning Running Indicator
0: OFF 1: ON
- - Bit 5
SV1 Indicator Multi SV1 Selecting Indicator
0: OFF 1: ON
- - Bit 6
SV2 Indicator Multi SV2 Selecting Indicator
0: OFF 1: ON
- - Bit 7
SV3 Indicator Multi SV3 Selecting Indicator
0: OFF 1: ON
- - Bit 8
AL1 Indicator Alarm Output 1 Indicator
0: OFF 1: ON
- - Bit 9
AL2 Indicator Alarm Output 2 Indicator
0: OFF 1: ON
- - Bit A
MAN Indicator Manual Control Indicator
0: OFF 1: ON
- - Bit B
DI-I Input DI-1 Input Status
0: OFF 1: ON
- - Bit C
DI-2 Input DI-2 Input Status
0: OFF 1: ON
- - Bit D
31008(03EF)
-
Heater Current Value Monitoring
0.0 ~ 50.0
- -
 Consists of the 31007(03EE) Address bit data.
Bit F
Bit E
Bit D
Bit C
Bit B
Bit A
Bit 9
Bit 8
- - DI-2 Input DI-1 Input MAN Ind. AL2 Ind. AL1 Ind. SV4 Ind.
0 0 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1
1 Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
SV3 Ind. SV2 Ind. AT Ind. OUT2 Ind. OUT1 Ind. % Ind. ℉ Ind. ℃ Ind.
0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1
1 Byte
