Autonics TK Series User Manual For Communication

Autonics 2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 21
2.4.3 Parameter 2 Setting Group [Func: 03/06/16, RW:
R/W]
No(Address)
Parameter
Description
Setting Range
Unit
Factory Default
40101(0064)
AT
Auto Tune Run/Stop
0: OFF 1: ON
-
OFF
40102(0065)
H-P
Heating Proportional Band
1~9999: 00)1~99(9
℃/℉/%
010.0
40103(0066)
C-P
Cooling Proportional Band
40104(0067)
H-I
Heating Integral Time
0~9999: 0000~9999
Sec.
0000
40105(0068)
C-I
Cooling Integral Time
40106(0069)
H-D
Heating Derivative Time
0~9999: 0000~9999
Sec.
0000
40107(006A)
C-D
Cooling Derivative Time
40108(006B)
DB
Dysfunction Band : It may
occur in the course of
processing Heating-
Cooling
Control
- Proportional Band ~ )0 ~
+Proportional Band (Based on smaller proportional
band value)
<ON/OFF – ON/OFF Control>
-999~0999 (H)
`9(9 ~ 99(9 (L)
Digit
0000
-9(9~ 09(9 (Analog)
%F.S
000.0
40109(006C)
REST
Manual Reset, in the
Proportional Control Mode
0~1000: 00)0 ~ 10)0
%
05)0
40110(006D)
hHYS
Heating Hysteresis
1~100: 001~100(Temperature H, Analog)
1~1000: 00)1~10)0(Temperature L)
Digit
002
40111(006E)
hOST
Heating OFF offset
0~100: 000~100(Temperature H, Analog)
0~1000: 00)0~10)0(Temperature L)
Digit
000
40112(006F)
cHYS
Cooling Hysteresis
1~100: 001~100(Temperature H, Analog)
1~1000: 00)1~10)0(Temperature L)
Digit
002
40113(0070)
cOST
Cooling OFF offset
0~100: 000~100(Temperature H, Analog)
0~1000: 00)0~10)0(Temperature L)
Digit
000
40114(0071)
L-MV
MV Low-limit Set Value
00)0~H-MV - )1(Heating or Cooling Control)
`0)0 ~ 00)0 (Heating & Cooling Control)
%
000.0
`00.0
40115(0072)
H-MV
MV High-limit Set Value
L-MV+)1~10)0 (Heating or Cooling Control)
00)0~10)0 (Heating & Cooling Control)
%
10)0
10)0
40116(0073)
RAMU
Ramp Up-Change Rate
0~999: 000~999(Temperature H, Analog)
0~9999: 00)0~99(9(Temperature L)
Digit
000
40117(0074)
RAMD
Ramp Down-Change Rate
0~999: 000~999(Temperature H, Analog)
0~9999: 00)0~99(9(Temperature L)
Digit
0000
40118(0075)
rUNT
Ramp Time Unit
0: SEC 1: MIN 2: HOUR
-
MIN
40119~40150
Reserved
