Ampere(DC) 10A(Yellow)
<HOLD>Hold
<Fn>Function Mode
<F1>Zero
<F2>20A/mA
0.00A
RedBlack
12
●
Enter the function item, displayed as shown below:
●
Insert the red probe into the “Ω” jack and the black probe into
the “COM” jack;
●
Press [F2] key and switch to detect high current mode as
shown below:
●
In the high current mode, the maximum measurable current is
20A and the maximum measurable continuous current is 10A.
There is 15A 30V self-recovery fuse inside, which can protect
the instrument from damage due to excessive current in the
use of vehicle detection. However, the detection of current in
220V / 380V strong current circuit cannot prevent damage
caused by excessive current, and cannot exceed the measur-
able current range during use.
Resistance
test
