PARTS LIST OF OUTDOOR UNIT EXPLODED PICTURE (ASW-H09A4/SAR1DI)

No. Chinese Name Name Qua.

1 面板网罩 Panel net 1

2 面板组件 Panel 1

3 顶盖板 Top cover board 1

4 轴流风扇 Axial-flow fan 1

5 风扇电机 Fan motor 1

6 电机支架 Motor bracket 1

7 冷凝器总成 Condenser assembly 1

8 冷凝器夹块 Condenser clamp 1

9 冷凝器海绵 Condenser sponge 1

10 背部钢丝网罩 Back steel net 1

11 隔离橡胶块 Partition rubber block 2

12 温控探头固定座 Fixed stand of temperature sensor 1

13 电器架盖板 Electric board cover 1

14 室外传感器 Outdoor temperature sensor 1

15 整流桥 Commutating element 1

16 PM 模块 PM module 1

17 电源控制主板 Main board 1

18 PFC 模块及电抗组件 PFC module and reactance element 1

19 散热片 Radiating fin 1

20 四位端子板 Four phase terminal board 1

21 电器架 A Electric board A 1

22 电器盖板 Handle 1

23 右侧板 Right side plate 1

24 隔风立板组件 Partition panel 1

25 四通阀线圈 Four way valve circuit 1

26 四通阀管路组件 Four way valve assembly 1

27 截止阀组件 B Liquid valve assembly 1

28 截止阀组件 A Gas valve assembly 1

29 阀板 Valve panel 1

30 压缩机消音棉 A Anti-acoustic sponge A of compressor 1

31 压缩机消音棉 B Anti-acoustic sponge B of compressor 1

32 压缩机消音棉 C Anti-acoustic sponge C of compressor 1

33 压缩机连接线 Connected line of compressor 1

34 压缩机接地线 Earth line of compressor 1

35 压缩机接线端子盖 Terminal cover of compressor 1

36 压缩机组件 Compressor 1

37 压缩机底部消音棉 Bottom anti-acoustic sponge of compressor 1

38 橡胶垫 Rubber cushion of compressor 3

39 底盘组件 Chassis assembly 1
