AV Access eShare W80 - HDMI Input and Output Matching Setting

Web UI
www.avaccess.com
17
info@avaccess.com
UI Element
Description
HDMI out1
resolution
Set the output resolution of HDMI out1. Two
operation methods are offered in the following:
 Auto: select to output the maximum resolution
supported by the display based on the display’s
EDID. e.g. If display supports
up to 4K@30Hz,
the device will output 4K@30Hz video.

Resolution range list: select a desired output
resolution from the dropdown menu to output
this fixed resolution. Maximum supported
resolution is 4K@30Hz.
By default, it's set as Auto.
HDMI out2
resolution
Set the output resolution of HDMI out2. Two
operation methods are offered in the following:
 Auto: select to output the maximum resolution
supported by the display based on the display’s
EDID.
e.g. If the display supports up to 1080p@60Hz,
the device will output 1080p@60Hz video.

Resolution range list: select a desired output
resolution from the dropdown menu to output
this fixed resolution. Maximum supported
resolution is 1080p@60Hz.
By default, it's set as Auto.
Refresh
Click to refresh to the latest status of the output
resolution.
Output HDCP
Support
To enable or disable HDCP encryption for the HDMI
out 1-2. Two options are offered in the following:
 Enable: select to enable HDCP encryption for
the HDMI output.
 Disable: select to disable HDCP encryption for
the HDMI output.
By default, it's set as Enable.
Auto
Standby
Set the period of time before the countdown timer
begins for auto standby.
• For example, when the current output is Guide
Screen, 1 minute auto standby means if there’s
no signal present at the display for 1 minute,
the countdown timer for display standby
begins; when the countdown is over, the
display enters standby mode.
