AV Access eShare W80 - Output Video Port; Output Video Signal; Output Resolutions; Audio

Specifications
www.avaccess.com
24
info@avaccess.com
Technical
1920x1080
2
(1080p24), 1920x1080
3
(1080p25),
1920x1080
5
(1080p30), 1920x1080
6
(1080p50),
1920x1080
8
(1080p60)
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at
30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz
Audio
Input Audio Port
2 x HDMI; 1 x LAN; 1 x WLAN
Input Audio Signal
RAW PCM 2.0, 16 bit, 32/44.1/48KHz sps
Output Audio Port
1 x HDMI OUT (HDMI OUT 1), 1 x Analog Audio OUT
Output Audio Signal
RAW PCM 2.0, 16 bit, 48KHz sps
Wi-Fi
Standard
IEEE 802.11 a/b/g/n/ac
Frequency
Dual bands, 2.4~2.4835GHz, 5.0~5.8GHz
Security
WEP, TKIP, AES, WPA, WPA2
Control
Control Connector
1 x RJ45, 10/100/1000Mbps Ethernet
Control Method
LAN (Web UI)
General
Operating Temperature
0°C to + 45°C (32 to + 113 °F)
Storage Temperature
-20 to +70°C (-4 to + 158 °F)
Humidity
10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/±4kV (Contact discharge)
Power Supply
12V 3A DC
Power Consumption
26.5W (Max)
Device Dimensions
(W x H x D)
242.6mm x 29.1mm x 142mm / 9.55” x 1.14” x 5.59”
Product Weight
0.80kg/1.76lbs
