2.1 Power Connector
CCD comes with a round-headed DC-in jack that carries 12 – 24 V
DC
external power supply. To
prevent damage to the CCD, always use the verified power adapter provided by us.
▲ Figure: DC-in Jack
▲ Figure: Connecting Adaptor via DC-in Jack
CAUTION!
The power adapter may become warm to hot when in use. Do not cover the adapter and
keep it away from your body.
2.2 HDMI 1.4a Display Port
The HDMI (High Definition Multimedia Interface) port supports a Full-HD device such as a LCD TV or a
monitor to allow viewing on a larger external display. You could refer to Appendix B.1 for pin
assignments.
