- 3 -
1.1 Product Features
▪ Cross-platform capability to satisfy versatile application needs
▪ Streamline, modern design with IPS panel and projected capacitive multi-touch screen, giving
excellent user experiences
▪ Ease integration and configuration effort with rich I/O and wireless communication technology
▪ Scratch resistance, no moving parts, maintenance free
▪ Standard VESA mount support, simplifying the field installation
1.2 Technical Specification
Specification 7” 10.1”
Display Resolution 1024 x 600 1280 x 800
Luminance 300 nits 350 nits
Type TFT LED-backlit TN LCD TFT LED-backlit IPS LCD
Touch Type 10-point projected capacitive touch screen
System CPU & Chipset Intel® Atom™ Z3735G QC 1.33GHz Processor with Turbo Boost to 1.83GHz
Memory Onboard 2GB DDR3L 1600 MT/s (Z3735F)
Storage Onboard 32G eMMC
Power Input Voltage 12 – 24 VDC
Type AT mode
Battery 1 x RTC battery
I/O Power 1 x DC-in Jack
HDMI 1 x Standard HDMI 1.4a
USB 2 x USB 2.0
LAN 1 x RJ-45
Audio 1 x 3-pole 3.5mm Headphone Jack
Ethernet Speed 10/100
Communication Wi-Fi Built-in 802.11 b/g/n
Bluetooth Built-in Bluetooth 4.0
OS Support Windows Windows 10 IoT
Android Android 5.1
Linux Ubuntu 16.04 (kernel: V4.5)
Mechanical Construction Plastic
Dimension 191 x 124 x 30 mm 261 x 175 x 34 mm
Weight 580 g 800 g
Mounting VESA (75 x 75)
Environmental Temperature Operating Temperature: 0°C ~ +40 °C
Storage Temperature: -20°C ~ +60°C
