AVANT 420 - Technical Specification

10
400 Series
Description of the loader
Technical specification
*) Load is measured at 400 mm from the attachment coupling plate, including attachment weight ( 70 kg ) and with counterweights.
Model AVANT 420 AVANT 423
Length 2195 mm 2195 mm
Width see table see table
Height 1980 mm 1980 mm
Weight 1030 kg 1080 kg
Standard wheels 23x8.50-12”grass/TR 23x8.50-12”grass/TR
Transmission, drive hydrostatic hydrostatic
Pulling force 700 kp 700 kp
Drive speed 12 km/h 12 km/h
Hydraulic oil tank capacity 26 l 26 l
Hydraulic oil type ISO VG 46 ISO VG 46
Auxiliary hydraulics oil flow / pressure 31 l/min 185 bar 34 l/min 185 bar
Turning radius inside/outside 880 / 1970 mm 880 / 1970 mm
Max. lifting height 2750 mm 2750 mm
Max. lifting capacity (hydr.) 690 kg 690 kg
Max. tipping load* 550 kg 550 kg
Max. breakout force / 50 cm 650 kg 650 kg
Sound pressure level 2000/14/EC L
P
81 dB (A) 81 dB (A)
Sound power level 2000/14/EC L
W
96 dB (A) 96 dB (A)
Hand-arm vibration, total
< 2,5 m/s² < 2,5 m/s²
Whole-body vibration, max. < 0,5 m/s² < 0,5 m/s²
2195 mm
710 mm 1100 mm 385 mm
2750 mm
2265 mm
1980 mm
200 mm
600 mm
990 -1095 mm
1980 mm
